STC-4SS-3528-C Langevin Transducer for Cleaner

Ultrasonic Transducers

STC 4SS 3528 C med
Horn Surface With Threaded
hole for mounting

pdf-icon_sm Data Sheet STC-4SS-3528-C  (Horn Surface w/ Threaded hole)

General Application

Ultrasonic Cleaning

Specifications

Parameter SpecificationRemarks
Resonant Fequency fr 28 ± 1 kHz HP-4194 Impedance Analyzer at 1Vrms
Resonance Resistance Ro Max -  25 ohm HP-4194 Impedance Analyzer at 1Vrms
Static Capacitance Cp 4100pF ± 10% LCR meter at 1kHz, 1Vrms
Mass g 410 g
Max Diameter D 45 mm
Length L 71.3mm
Max Input Voltage P 2000Vp-p
Max Input Power P 50 W

Tests environmental conditions: 23 ± 3 °C; 40 ~ 70% RH

Mounting options and dimensions

  • Threaded mounting hole in the horn surface for screw fixing

STC 4SS03528C DimHow to order

If you need a specific quote, please request so by sending us an e-mail through "Request for Quote" by refering to the following part number or by calling us at 814-861-5688 (8:30am to 5:30pm EST). You can also directly place an order by calling us with your credit card information or sending us a Purchase Order form.

Purchasing Options

ArticlePart NumberPrice unit

Bolt Clamped Langevin Ultrasonic Transducer
Horn with Threaded Hole

STC-4SS-3528-C

1-9: $105.00

10-24: $65.00

25-99: $50.00

**Prices are for reference and subject to change without notice!
