STH-S44-5015 High Power Langevin Transducer
Ultrasonic Transducers
 |
 |
General Application
High Power Ultrasonic (ex. ultrasonic welding)
Specifications
Tests environmental conditions: 23 ± 3 °C; 40 ~ 70% RH
| Parameter | Specification | Remarks | |
|---|---|---|---|
| Resonant Fequency | fr | 15 ± 1 kHz | HP-4194 Impedance Analyzer at 1Vrms |
| Resonance Resistance | Ro | < 12 ohm | HP-4194 Impedance Analyzer at 1Vrms |
| Static Capacitance | Cp | 13.8nF ± 20% | LCR meter at 1kHz, 1Vrms |
| Bandwidth | > 1 kHz | ||
| Insulation Resistance | > 2000 Mohm | ||
| Max. Input Power | Pin | 700 W | |
| Max. Voltage | Vin | 4000 Vpk-Pk | |
| Length | L | 154 mm | |
| Weight | |||
| Joint Bolt | M16 x 1.0 |
How to order
If you need a specific quote, please request so by sending us an e-mail through "Request for Quote" by refering to the following part number or by calling us at 814-861-5688 (8:30am to 5:30pm EST). You can also directly place an order by calling us with your credit card information or sending us a Purchase Order form.
Purchasing Options
| Article | Part Number | Price unit |
|---|---|---|
|
Bolt Clamped Langevin Ultrasonic Transducer |
STH-S44-5015 |
1-9: $185.00 10-99: $140.00 100-499: $115.00 |
